The most important point to note is to make sure that the desired pin-shared function is properly
selected and also deselected. To select the desired pin-shared function, the pin-shared function
should rst be correctly selected using the corresponding pin-shared control register. After that the
corresponding peripheral functional setting should be congured and then the peripheral function
can be enabled. To correctly deselect the pin-shared function, the peripheral function should rst be
disabled and then the corresponding pin-shared function control register can be modied to select
other pin-shared functions.
Register
Name
Bit
7 6 5 4 3 2 1 0
PAS0 PAS07 PAS06 PAS05 PAS04 PAS03 PAS02 PAS01 PAS00
PAS1 PAS17 PAS16 — — PAS13 PAS12 PAS11 PAS10
PBS0 PBS07 PBS06 PBS05 PBS04 PBS03 PBS02 PBS01 PBS00
PBS1 PBS17 PBS16 PBS15 PBS14 PBS13 PBS12 PBS11 PBS10
PCS0 PCS07 PCS06 PCS05 PCS04 PCS03 PCS02 PCS01 PCS00
PES0 PES07 PES06 PES05 PES04 PES03 PES02 PES01 PES00
PES1 — — — — PES13 PES12 PES11 PES10
IFS — — IFS5 IFS4 IFS3 IFS2 IFS1 IFS0
Pin-shared Function Selection Registers List – BS66F340
Register
Name
Bit
7 6 5 4 3 2 1 0
PAS0 PAS07 PAS06 PAS05 PAS04 PAS03 PAS02 PAS01 PAS00
PAS1 — — — — PAS13 PAS12 PAS11 PAS10
PBS0 PBS07 PBS06 PBS05 PBS04 PBS03 PBS02 PBS01 PBS00
PBS1 PBS17 PBS16 PBS15 PBS14 PBS13 PBS12 PBS11 PBS10
PCS0 PCS07 PCS06 PCS05 PCS04 PCS03 PCS02 PCS01 PCS00
PCS1 PCS17 PCS16 PCS15 PCS14 PCS13 PCS12 PCS11 PCS10
PDS0 PDS07 PDS06 PDS05 PDS04 PDS03 PDS02 PDS01 PDS00
PDS1 PDS17 PDS16 PDS15 PDS14 PDS13 PDS12 PDS11 PDS10
PES0 PES07 PES06 PES05 PES04 — — — —
PES1 PES17 PES16 PES15 PES14 PES13 PES12 PES11 PES10
IFS — — IFS5 IFS4 IFS3 IFS2 IFS1 IFS0
Pin-shared Function Selection Registers List – BS66F350
Register
Name
Bit
7 6 5 4 3 2 1 0
PAS0 PAS07 PAS06 PAS05 PAS04 PAS03 PAS02 PAS01 PAS00
PAS1 — — — — PAS13 PAS12 PAS11 PAS10
PBS0 PBS07 PBS06 PBS05 PBS04 PBS03 PBS02 PBS01 PBS00
PBS1 PBS17 PBS16 PBS15 PBS14 PBS13 PBS12 PBS11 PBS10
PCS0 PCS07 PCS06 PCS05 PCS04 PCS03 PCS02 PCS01 PCS00
PCS1 PCS17 PCS16 PCS15 PCS14 PCS13 PCS12 PCS11 PCS10
PDS0 PDS07 PDS06 PDS05 PDS04 PDS03 PDS02 PDS01 PDS00
PDS1 PDS17 PDS16 PDS15 PDS14 PDS13 PDS12 PDS11 PDS10
PES0 PES07 PES06 PES05 PES04 PES03 PES02 PES01 PES00
PES1 PES17 PES16 PES15 PES14 PES13 PES12 PES11 PES10
PFS0 — — — — PFS03 PFS02 PFS01 PFS00
IFS — — IFS5 IFS4 IFS3 IFS2 IFS1 IFS0
Pin-shared Function Selection Registers List – BS66F360
