BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
Name
Bit
7 6 5 4 3 2 1 0
PAS0 PAS07 PAS06 PAS05 PAS04 PAS03 PAS02 PAS01 PAS00
PAS1 — — — — PAS13 PAS12 PAS11 PAS10
PBS0 PBS07 PBS06 PBS05 PBS04 PBS03 PBS02 PBS01 PBS00
PBS1 PBS17 PBS16 PBS15 PBS14 PBS13 PBS12 PBS11 PBS10
PCS0 PCS07 PCS06 PCS05 PCS04 PCS03 PCS02 PCS01 PCS00
PCS1 PCS17 PCS16 PCS15 PCS14 PCS13 PCS12 PCS11 PCS10
PDS0 PDS07 PDS06 PDS05 PDS04 PDS03 PDS02 PDS01 PDS00
PDS1 PDS17 PDS16 PDS15 PDS14 PDS13 PDS12 PDS11 PDS10
PES0 PES07 PES06 PES05 PES04 PES03 PES02 PES01 PES00
PES1 PES17 PES16 PES15 PES14 PES13 PES12 PES11 PES10
PFS0 — — — — PFS03 PFS02 PFS01 PFS00
PGS0 PGS07 PGS06 PGS05 PGS04 PGS03 PGS02 PGS01 PGS00
PGS1 PGS17 PGS16 PGS15 PGS14 PGS13 PGS12 PGS11 PGS10
IFS — — IFS5 IFS4 IFS3 IFS2 IFS1 IFS0
Pin-shared Function Selection Registers List – BS66F370
• PAS0 Register
Bit 7 6 5 4 3 2 1 0
Name PAS07 PAS06 PAS05 PAS04 PAS03 PAS02 PAS01 PAS00
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit 7~6 PAS07~PAS06: PA3 pin function selection
00/11: PA3
01: SCS
10: XT1
Bit 5~4 PAS05~PAS04: PA2 pin function selection
PAS0[5:4] BS66F340 BS66F350 BS66F360 BS66F370
00 PA2/CTCK1 PA2 PA2 PA2
01 SCS SCS SCS SCS
10 PA2/CTCK1 PA2 PA2 PA2
11 PA2/CTCK1 PA2 PA2 PA2
Bit 3~2 PAS03~PAS02: PA1 pin function selection
00/10/11: PA1
01: CTP0
Bit 1~0 PAS01~PAS00: PA0 pin function selection
00/10/11: PA0
01: SDO
