List of Field-Replaceable Components
8500C/8500C+ System Maintenance Manual 5-73
5-18 10 * * Drive, 3.5” Floppy Disk, 720K
(8500C)
8V413 MP F920-1/121 610-253
5-18 10 * * Drive, 3.5” Floppy Disk, 144MB
(8500C+)
99866 - 12645
5-18 11 * * Tear Bar 99866 − 10998
5-18 13 * * Printer Assembly 99866 − 10832
5-18 − * * * Printer, Mech. Thermal 320 Dot 62712 STP411B-320 610-195
5-18 13 (13) * * * Paper Bar 99866 − 8697
5-18 13 (17) * * * Shield 99866 − 11334
5-18 14 * * Rubber Gromment Shockmount
Qty. 4
Cabot G601-1 610-197
5-18 15 * * Nut Fin Shockmount Qty. 4 99866 − 8745
5-18 16 * * Standoff, Spring Qty. 1 99866 − 10797
5-18 17 * * Knob, 1/2 Dia., 1/8 Shaft, Black
Qty. 2
95146 KLN-500B-1/8 601-004
5-17 20 * * Washer Shoulder #4 Qty. 10 04713 B51547F019 654-4SBA
5-18 21 * * Bumper, Rubber Qty. 4 76385 ZB-1160-MI 610-094
5-17 22 * * Sandoff 4-40 1/2” Nylon Hex Qty.
2
83330 4306 660-3444
5-17 24 * * Graphics Module (8500C) 99866 − 10828
5-17 24 * * Graphics Module (8500C+) 99866 − 14574
5-18 27 * * Tear Bar 99866 − 10997
5-17
5-18
28 * * Standoff, #4 Clear Rnd. 1/4 O.D.,
Qty 5
83330 8481 660-2424
5-18 29 * * Screw, 4-40 X 3/16 Pan Php, Cad.,
Qty. 2
96906 MS35206-212 651-4550
5-18 30 * * Screw, 4-40 X 3/16 Flt., Php. Cad,
Qty. 4
96906 MS35190-220 651-4570
5-18 31 * * Screw, 4-40 X 3/8, Blk, 82 Deg.
Flt. Qty. 3
96906 MS51959-16B 651-4573B
5-17
5-18
32 * * Screw, 4-40 X 3/16 Php. Blk. Qty.
18
96906 MS51957-12B 651-4520
5-17 33 * * Screw, 4-40 X 1/4 Pan Php. Blk.
Qty. 4
96906 MS51957-13B 651-4521
Table 5-15. 8500C/C+ Balancer/Analyzer
FIG
NO.
REF
NO.
COMPONENT
1 2 3 4 6 7 8 (Assy. Level) CAGE MFG. P/N C-H P/N
(Continued)
