Honeywell Chadwick-Helmuth 8500C User Manual

5-72 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Chapter 5 - Maintenance And Repair
5.10List of Field-Replaceable Components
Table 5-15. 8500C/C+ Balancer/Analyzer
FIG
NO.
REF
NO.
COMPONENT
1 2 3 4 6 7 8 (Assy. Level) CAGE MFG. P/N C-H P/N
5-17
5-18
− * 8500C Balancer/Analyzer 99866 − 10800A
5-17
5-18
− * 8500C+ Balancer/Analyzer 99866 − 10800-2
5-17 A1 * * 8500C Digital Board 99866 − 11084
5-17 A1 * * 8500C+ Digital Board 99866 − 14541-1
5-17 A-2 * * Analog Board 99866 − 13824
5-18 A3 * * Power Supply Board 99866 − 11032A
5-18 − * * * Fuse, 2.5A 250V FAST 5x 03614 GDB2.5A 301-20258
5-17 A4 * * Heater/EL Control Board 99866 − 10827
5-17 − * * * Fuse, 2.5A 250V FAST 5x 03614 GDB2.5A 301-20258
5-18 A5 * * Distribution Board 99866 − 11160
5-15 U8 * * 8500C EPROM, Low Memory 99866 − 10927-X
5-15 U6 * * 8500C+ EPROM, Low Memory 99866 − 14820-X
5-15 U9 * * 8500C EPROM, High Memory 99866 − 10928-X
5-15 U9 * * 8500C+ EPROM, High Memory 99866 − 14821-X
5-17 1 * * 8500C Keypad Panel 99866 − 11004
5-17 1 * * 8500C+ Keypad Panel 99866 − 14568
5-18 2 * * Chassis 99866 − 10737A
5-18 3 * * Cover 99866 − 10676B
5-17 4 * * Bezel 99866 − 10689A
5-18 5 * * Door Latch 99866 − 10771
5-18 6 * * Base, Door Latch 99866 − 10770A
5-18 7 * * Spring, Door Latch 99866 − 10772
5-18 8 * * Plate, Disk Mount 99866 − 10694
5-18 9 * * Bracket, Disk Support 99866 − 10677
X = Latest eprom configuration
