Honeywell Chadwick-Helmuth 8500C - Table 5-15. 8500 C;C+ Balancer;Analyzer

5-74 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Chapter 5 - Maintenance And Repair
5-18
5-19
34 * * Harness Assembly 99866 − 11201
5-18 36 * * Screw, 10-32 X 5/16 Php. Blk.,
Qty. 4
............. − 651-9422
5-17 38 * * Spacer, 1/2” 1/4 O.D. #4 Nylon,
Qty. 2
83330 4018 660-D444
5-17 39 * * Standoff, 4-50 X 5/8 Hex Met.
Qty. 2
83330 8404 660-1454
5-17 40 * * Standoff, 4-40 X 13/16” Hex, Qty.
4
83330 9289 660-1475B
5-17 41 * * Spacer, #4 X 5/16” Nylon (Rnd),
Qty. 3
83330 4009 660-D434
5-18 42 * * Washer, #4 Std. Flt, 315” Qty. 7 96906 MS51412-20 654-4SFC
5-17
5-18
43 * * Screw, 4-40 X 1/4 Pan Php. Cad.,
Qty. 16
96906 MS51957-13 651-4531
5-17 44 * * Screw, 4-40 X 7/8 Pan Php. Cad.,
Qty. 2
96906 MS51957-20 651-4537
5-17 45 * * Screw, 4-40 X 3-8 Pan Php. Blk
Qty. 4
96906 MS51957-15B 651-4523
5-17 46 * * Washer #4 Lock Split Ring qty. 6 83330 5850-11 654-4SPA
5-18 47 * * Nut 4-40 Nylon Lock Thin Qty. 4 39428 90633A005 654-45NT
5-18 48 * * Screw, 4-40 X 1/2 Php. Black,
Qty. 2
96906 MS35216-16B 651-4524
5-17,
5-18
49 * * Nut, 4-40 Nylon Lock Standard,
Qty. 13
39428 90631A005 652-45NS
5-18 50 * * Gasket 0N083 GS2100-060-
0250-SC
610-258
5-18 51 * * Insulator, Disk Drive 99866 − 10894
* * Insulator, Analog PCB 99866 − 10958
5-17 53 * * Spring, Paper Holder 99866 − 610-205
−− * * Gasket, Form 1/4” THK X 3/8”
Wide
91573 1211T
Polyurethane
610-265
5-17 55 * * Spacer, Nylon #4 X 5/16 “D” 99866 − 11421
5-17 − * * Battery Pack, 3.6V NiCad 500-103 610-189
Table 5-15. 8500C/C+ Balancer/Analyzer
FIG
NO.
REF
NO.
COMPONENT
1 2 3 4 6 7 8 (Assy. Level) CAGE MFG. P/N C-H P/N
(Continued)
