8500C/8500C+ System Maintenance Manual 5-47
c. Hold disk with arrow facing up and pointing in and insert disk in 8500C/C+ disk drive-
push in until drive button pops out (Figure 2-1).
d. Press STATUS.
e. Press FORMAT DSK soft key.
f. Press FORMAT soft key.
g. Because the cleaning disk contains no magnetic media, the message, DISK IS NOT
CORRECTLY FORMATTED! will appear. Press CANCEL soft key to continue format
procedure.
h. Press EXIT soft key when format is complete.
5.7.2 Inspection
Inspect components of the 8500C/C+ system in accordance with Table 5-13.
Table 5-13. Inspection
Item Inspect for Remedy
Major components
Cables
1. Dust, dirt, or other
foreign matter.
2. Check printed circuit
boards for cracks or
breaks, peeling circuit
traces, loose or missing
electrical parts, and
solder joints for corrosion
or damage.
3. Check connectors for
bent or broken pins,
corrosion, arcing, or
damage.
1. Breaks, tears, fraying,
burrs, or other damage.
2. Check connectors for
bent or broken pins,
corrosion, arcing, or
damage.
1. Clean as necessary.
2. Replace circuit boards as
necessary.
3. Repair connectors or
replace harness
assemblies as necessary.
1. Repair or replace cables
as necessary.
2. Repair connectors or
replace as necessary.
