1-8 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Chapter 1 - Introduction
Table 1-2. System Interconnect Cables
Part No. Nomenclature Purpose Qty.
10811-12 Cable, Signal
Selector (12 ft)
Connects signals between 8500C/C+. 1
11210-50 Cable, Velocimeter
(50 ft)
Connects Velocimeter to 8520C or
8500C/C+ via 8998 cable.
up to 12
11210-20 Cable, Velocimeter
(20 ft)
Connects Velocimeter to 8520C or
8500C/C+ via 8998 cable.
up to 12
8998 Cable, Input
Adapter
Connects 8500C/C+ to power,
Velocimeter, and magnetic pickup/
photocell inputs when 8520C is not
used.
1
10813-12 Cable, DC Power
(12 ft)
Connects 28 VDC power to 8520C. 1
10808-25 Cable, Magnetic
Pickup (25 ft)
Connects magnetic pickup to 8500C/
C+ or 8520C via 10809 cable.
1
10185 Cable, Photocell Connects optical probe to photocell
processor 10170
1
3529 Cable, DC Power
Extension
Connects DC power to 8500C/C+ or
8520C.
1
Table 1-3. Basic System Accessories
1
Part No. Nomenclature Purpose Qty.
Model 11A Calibrator Bench tests 8500C/C+ system. 1
10170 Photocell Processor Processes optical inputs for the
8500C/C+ via the 8520C or cable
8998.
1
135M-12 Strobex Hand-held strobe, illuminates
reflective targets on blades for
tracking purposes.
1
11800 FasTrak Day-Night optical tracker, used in
place of Strobex. Communicates with
8500C/C+ Smart Chart software.
1
10200 Optical Probe Provides optical inputs to photocell
processor 10170.
1
