Honeywell Chadwick-Helmuth 8500C - Table 5-7. Specification: Spectrum Accuracy, Low Frequency Range

5-28 Chadwick-Helmuth A Business Unit of Honeywell International, Inc.
Chapter 5 - Maintenance And Repair
NOTE: Fundamental peaks must be within range of 9.5 to 10.4 IPS inclusive.
8500C/C+ Firmware Version: _________ 8500C/C+ Serial Number: ________ Date: _______
Table 5-7. Specification: Spectrum Accuracy, Low Frequency Range
Input
Frequency
Fundamental
Peak
490.0 Hz
(29400 rpm) ______ IPS
406.0 Hz
(24360 rpm) ______ IPS
308.0 Hz
(18480 rpm) ______ IPS
210.0 Hz
(12600 rpm) ______ IPS
154.0 Hz
(9240 rpm) ______ IPS
98.0 Hz
(5880 rpm) ______ IPS
51.0 Hz
(3060 rpm) ______ IPS
21.0 Hz
(1260 rpm) ______ IPS
9.0 Hz
(540 rpm) ______ IPS
6.0 Hz
(360 rpm) ______ IPS
3.0 Hz
(180 rpm) ______ IPS
