Overview
E-Mon® Series - Global User Manual
54-000-01-ENG01-0121
Page | 23
• The current sensors require UL1015 standard hookup wire leads for connection.
• Wires shall be AWG grade with a temperature range of -25 to 105 ºC and voltage range of
up to 480 V.
CS Model/ Number
Current Measurement
Mounting
Secondary Output
E10025 – 333V
25 A
Split Core
0.333 VAC
E10050 – 333V
50 A
E10100 – 333V
100 A
E10200 – 333V
200 A
E10400 – 333V
400 A
E10800 – 333V
800 A
E101600 – 333V
1600 A
E103200 – 333V
3200 A
E-RS-5000-333V
5000 A
Split Rope
Table 3. Current Sensors for E-Mon Energy Meter
NOTE
• The meter has been tested for 100 A to 320 A, additional testing required to ensure
safe operation.
• Check the App for to ensure correct CS selection and settings.
• Use conduit fittings that maintains the environmental rating of the type 4 when
installing CS meter polymeric enclosure.
• The CS ratings shall have a branch circuit protection.
• Rated Current = 15 A.
• The indirect version of meter comes with the CS, however if one component is
ordered wrong the entire setup may require an exchange.
ATTENTION: Electrical Hazard!
• Reduce electrical shock while interacting with the meter components such as Front
Panel/Mounting/Connections.
• Always open or disconnect the monitored circuit from power-distribution system (or
service) of building before installing or servicing current-sensing devices.
• Apply required current input and output settings during meter commissioning.
