Honeywell Galaxy Dimension series Integration Guide

Supported number of devices and entities
gtap.genetec.com | Honeywell Galaxy Control Panel Integration Guide 5.2 9
EN.550.007-V5.2.C4(3) | Last updated: March 11, 2014
Supported number of devices and entities
The following table lists the number of intrusion detection units, intrusion detection areas,
inputs, and outputs that are supported in Security Center.
Supported features
The following table lists the Security Center intrusion detection features that are supported with
the Honeywell Galaxy Dimension control panel integration.
No. of intrusion
detection units
No. of intrusion
detection areas
No. of inputs No. of outputs
Per server 10 5200 5200 2600
Per Directory 200 10400 10400 52000
Feature Supported
Serial connection Ye s
RS-232 serial connection Ye s
TCP/IP connection Yes, with Galaxy Ethernet
Module E080-4
Data encryption over TCP/IP No
Authentication between control panel and server Ye s
Input bypass Yes (report only)
Arm/disarm from Security Center Instant arming/disarming Yes
Delayed arming No
Use control panel inputs in virtual zones See limitation 57040
Trigger outputs on control panels Ye s
Discover intrusion detection areas and devices
automatically
No. Only the panel is
automatically detected at
enrollment
Create intrusion detection areas automatically in
Security Center
No. Must activate and
configure manually
Create input entities automatically in Security Center No. Must activate and
configure manually

Honeywell Galaxy Dimension series Specifications

General

Model	Galaxy Dimension series
Users	Up to 250
Partitions	Up to 8
Operating Temperature	-10°C to +55°C
Compatibility	Honeywell Galaxy accessories and peripherals
