Honeywell Galaxy Dimension series Integration Guide

Configuring the intrusion detection unit
gtap.genetec.com | Honeywell Galaxy Control Panel Integration Guide 5.2 27
EN.550.007-V5.2.C4(3) | Last updated: March 11, 2014
Map inputs to intrusion detection areas
By default, when you receive events from the control panel in Security Desk, you are only told
which input triggered the event. For example, if an area is master armed and an intrusion event
occurs, you will only know which input triggered the event. To know where the input is located,
you need to map the inputs to intrusion detection areas (groups).
Before you begin: Activate the inputs and the intrusion detection areas to monitor in the
intrusion detection unit Properties tab. See "Configure intrusion detection unit properties" on
page 24.
1 From the Intrusion detection task in Config Tool, select the intrusion detection unit to
configure, and click the Peripherals tab.

Honeywell Galaxy Dimension series Specifications

General

Model	Galaxy Dimension series
Users	Up to 250
Partitions	Up to 8
Operating Temperature	-10°C to +55°C
Compatibility	Honeywell Galaxy accessories and peripherals
