21
GasAlertMaxXT II
Installing Fleet Manager II
Installing Fleet Manager II
Fleet Manager II is required to configure the detector. To install Fleet
Manager II, refer to the Fleet Manager II CD-ROM that includes the
• installation wizard, and
• Fleet Manager II Operator’s Manual.
From the User Options tab in Fleet Manager II, two sections are
provided to add data, enable/disable features, and to define settings for
the sensors and the detector. They are as follows:
•
Device Configuration
• Sensor Configuration
Using Fleet Manager II to Configure the Detector
When Fleet Manager II is installed, refer to Table 5., Figure 3., and the
following procedures:
Table 5. Connecting the IR Link
Figure 3. Connecting the IR Link
1. Activate the detector and wait for the startup tests to
complete.
2. Connect the USB cable to the USB port on the computer.
3. Connect the USB cable to the IR Link.
4. Insert the IR Link into the IR interface on the back of the
detector.
5. From the PC, open Fleet Manager II.
6. Click Administration.
7. From the Administration toolbar, click Login / Logout
to access the Enter Password dialog box. Enter Admin
and click OK.
Item Description
1 IR and charger interface
2 GasAlertMaxXT II
3 IR Link
4 USB cable
