Installation and Setup
Equipment Required
The following tools may help you to complete the installation:
•Drill
• Screwdrivers
• Wire cutters
Overview of Installation Procedure
Note Please familiarize yourself with the installation procedure and complete each
step in the exact sequence given.
The initial installation of an HD4DIP(X) camera consists of the following steps:
Step See …
1 Install the conduit plug. page 22
2 Mount the camera. page 20
3 Connect the wiring. page 23
4 Adjust the camera angle, position, and
focus for optimum image.
page 27
5 Secure the enclosure cover. page 29
6 Program the camera. page 37
