HD4DIP Network Camera V2.1 Reference Guide
Document 800-04191 Rev A 25
06/09
Connecting to a Video Monitor
The analog video connection (see Figure 2-4) is available as a test output and should be
used during installation to position, aim and focus the camera, as needed. Connect the
video connector from the camera to the video input connector on your spot monitor.
Connecting Audio and Alarms
Figure 2-6 Audio and Alarm PINs
Connecting Audio
The HD4DIP(X) Network Camera supports bi-directional audio. There are two supported
voice band channels that function in full duplex mode. The camera can transmit audio from
the camera to the client (PC) using any audio source that provides an industry standard line
level input (see the terminal strip as depicted in Figure 2-5). The camera can also receive
audio from the client (PC) and provide an industry standard line level output (3.5 mm stereo
or mono jack) suitable to connect to audio devices. Audio input and output have 600 Ohm
impedance. See Configuring Audio on page 61 to configure audio options.
1
2
3
456
7
8
Table 2-1 Audio and Alarm Connector PIN Definitions
PIN Definition
1Audio In +
2Audio In -
3Audio Out +
4Audio Out -
5Alarm In +
6Alarm In -
7Alarm Out +
8Alarm Out -
