Web Operation | 169
800-18160 - B - 07/2014
Figure 5-35 Email Configuration Interface.
Table 5-16 Email Configurations
Parameter Description
Enable Click to enable the email function.
SMTP server Enter the email SMTP server IP.
Port Enter the corresponding port.
Anonymous Only available if the server supports the anonymity function.
This function allows you to automatically log in anonymously,
so you do not need to enter your user name, password, or
sender’s information.
User Name Enter the user name for logging in to the sender’s email box.
Password Enter the login password here.
Sender Enter the sender’s email address.
Encrypt Type Select from NONE, TLS, or SSL.
Title Enter an email subject. You can use up to 32 letters or
numbers.
Attachment Click to enable so that a snapshot can be attached to the
email.
Receiver Enter the receiver’s email address. You can enter up to 3 email
boxes.
