Web Operation | 199
800-18160 - B - 07/2014
Figure 5-65 GUI Configuration Interface
Enabling and Disabling Alarm Out Settings
Click Alarm Out in the General settings configuration interface to open the Alarm Out settings
configuration interface.
Table 5-25 GUI Configurations
Configuration Description
Resolution Select from four options: 1920x1080, 1280x1024 (default),
1280x720, and 1024x768.
Note You need to reboot the NVR to activate changes to the
resolution.
Transparency Configure the transparency of the GUI display. Select from
128 to 255.
Time Display/Channel
Display
Click to enable these functions, which display the time and
channel on the video monitor.
Image Enhance Check to enable Image Enhance, to optimize the preview
video.
