Honeywell HEN04101(X) User Manual

Web Operation | 189
800-18160 - B - 07/2014
Configuring the Channel for Schedules
Click Channel in the Schedule configuration interface to open the Channel configuration
interface.
Figure 5-53 Channel Configuration Interface
Configuring the Main Stream Channel
Select an HDD Group from the drop-down menu, then click Save. See Figure 5-53.
Configuring the Extra Stream Channel
You can select the corresponding HDD group for the sub stream.
1. Click the Extra Stream tab to open the Extra Stream configuration interface.
Figure 5-54 Extra Stream Configuration Interface
2. Select an HDD Group from the drop-down menu, then click Save.
Configuring the Image Storage Channel
You can select the corresponding HDD group for saving snapshots.
1. Click the Image Storage tab to open the Image Storage configuration interface.

Honeywell HEN04101(X) Specifications

General

Brand	Honeywell
Model	HEN04101(X)
Category	Network video recorder
Language	English
