Web Operation | 175
800-18160 - B - 07/2014
Table 5-18 Motion Detection Configurations
Configuration Description
Enable Click to enable motion detection. Select a channel from the
drop-down list.
Period Define a period during which motion detection is active.
1. Click Set. The Set configuration interface appears.
2. Select a day of the week from the drop-down menu. Select
from a day of the week, Work Day, or Free Day.
Note If you select Work Day or Free Day, a Set button
appears so you can configure which days are Work
Days and which days are Free Days. Click Set, select
the Work Days and the Free Days, then click OK.
Note You can configure up to 6 periods within one day.
3. Configure a time range for when the event detection area
is active, then click the check box to select that time range.
4. Click Save.
Sensitivity Select from six levels of sensitivity. The higher the number, the
higher the sensitivity.
