MAx panel Fire Detection System
M-167.3-Serie-MA-EN / 11.2021 5
1.2 DEFINITIONS
LINE: A physical line to which the intelligent field devices are connected:
• Detectors
• Audio / visual devices
• Manual call points (MCP)
• Input and output modules
POINTS: Are the intelligent field devices that can be connected to the FACP. A maximum of 50 points can be
associated to each zone.
ZONES: Are groupings of points. They serve as a basic indication to identify the physical position of an event.
MAx panel Max. number of zones
MA-1000 150
MA-2000 2000
MA-8000 2000
GROUPS: Are a software set that allows the necessary associations for the execution of an activation. The
maximum number of groups are:
• 400 in a standalone FACP
• 1600 in a network system
