Honeywell Mini-AT User Manual

97
Page 97
Mini-AT User Guide
Item
No. Item Name Description
————————————————————————————————————————
071 PULSER C ALARM
If the value at item 007 (Pulser C) exceeds the Pulser C Limit (item
071), an alarm is initiated. The LCD will display ‘dots’ while in
the Corrector Mode, and item 071 will display “11111111” if view
by the Meter Reader Mode or software. “00000000” is displayed
if item 071 has no alarm.
Default = 00000000
072 ALARM 1 ITEM # Item number for the first of three user-selectable, optional
alarms. Intended choices are:
000 = unassigned
105 = Pressure Out of Range
106 = Temperature Out of Range
Default = 000
073 ALARM 2 ITEM # Item number for the second of three user-selectable,optional
alarms. Intended choices are:
000 = unassigned
105 = Pressure Out of Range
106 = Temperature Out of Range
Default = 000
074 ALARM 3 ITEM # Item number for the third of three user-selectable, optional
alarms. Intended choices are:
000 = unassigned
105 = Pressure Out of Range
106 = Temperature Out of Range
Default = 000
075 MAG LIST 2 ITM 1
Item number of the first item displayed in MAG LIST #2. The
display of this selection follows the display of LIVE Parameters (if
enabled at item 129) or the last MAG LIST 1 ITEM (if enabled,
items 130-135). If neither LIVE Parameters nor MAG LIST 1
items are enabled, the item programmed into item 075 will be the
first Mag Read Item to be displayed in the Meter Reader List. Any
Mini-AT item number may be entered as a Mag Read Item.
Default = 200 (Site ID number)
076 MAG LIST 2 ITM 2 Item number of the next Mag List #2 item. Any item code may be
selected, or enter the value “255” at this item to indicate the
End-of-List.
Default = 113 (Hi Res CorVol)
077 MAG LIST 2 ITM 3 Same as Item 76 above.
Default = 013 (Base Pressure)
