68 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Program Autoprogram Menu
Figure 3.58 Autoprogram Confirmation Screen (SLCs)
Soft Keys
REVIEW: Press this
soft key to review the new devices found (with the option of adding them to
the program one by one), devices that are in the database that the autoprogram did not find, devices
that have data base and autoprogram information that differs, and devices that are incorrectly
doubled up on a single address. Devices will display in the following order:
• L01M001 through L01M159
• L01D001 through L01D159
• L02M001 through L02M159, etc.
Depending on what information was found, different sc
reens may appear for different points. Refer
to Figure 3.59 through Figure 3.62 for examples of the screens.
ACCEPT ALL: Press to accept all the
new devices that have been found by the autoprogram.
Errors and discrepancies will still be displayed the same as if the REVIEW soft key had been
pressed: however, new devices will not individually display for review and acceptance.
Add New Points
When the REVIEW soft key is pressed, the panel will individually display each new SLC point
found during autoprogramming. The screen below uses an SLC detector point as an example.
Figure 3.59 Autoprogram Confirmation Screen (New SLC Point)
AUTOPROGRAM CONFIRMATION
LOOP DETECTORS MODULES
1 011 087
2 030 129
3 NOT INSTALLED
4 NOT INSTALLED
5 NOT INSTALLED
6 NOT INSTALLED
7 NOT INSTALLED
8 NOT INSTALLED
9 NOT INSTALLED ACCEPT
10 NOT INSTALLED ALL
REVIEW BACK
AUTOPROGRAM CONFIRMATION
NEW DEVICE FOUND AT LXXXDXXX
ADD POINT?
YES NO
EDIT BACK
