SLC Circuits with Isolators Isolator Detector Bases
NOTE: For information on wiring an isolator base, refer to Figure 10.3, “Wiring a B224BI Isolator Base
Mounting Plate” on page 51.
Non-Isolating DeviceIsolator Base
X
Z
Control Panel
SLC Return
SLC Out
SLC-isowork.wmf
Detector 1
Detector 2
Detector 3
Detector 4
Detector 5
Y
Short-circuit path
Figure 5.3 Isolator Base Circuit: Sample Style 6 Wiring
