NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 101
Detector Sensitivity Settings Intelligent Sensing Applications
C.4 Detector Sensitivity Settings
C.4.1 How to Select Pre-Alarm and Alarm Sensitivity
Each detector provides a host of selectable intelligent options. The control panel provides nine
levels of Pre-Alarm (PA:1–PA:9) and Alarm (AL:1–AL:9) in percent per foot obscuration:
• PA:0 no Pre-Alarm selection.
• PA:1 usually the self-optimizing setting where the control panel selects a suitable
Pre-Alarm level for a detector.
• PA:2–PA:9 the detector Pre-Alarm sensitivity level - with PA:2 the most sensitive and PA:9
the least sensitive.
• AL:1–AL:9 the detector Alarm sensitivity level - with AL:1 the most sensitive and AL:9
the least sensitive.
NOTE: (d) Signifies the factory default setting in Table C.2.
Table C.2 Detector Sensitivity (in percent obscuration per foot) (1 of 2)
Detector Type Alarm (FlashScan) Alarm (CLIP) Pre-Alarm
Photo Electric
SMOKE (PHOTO)
(See note
*
)
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 % (d)
AL:9=2.35 %
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 % (d)
AL:9=2.35 %
PA:1=Auto
PA:2=0.30 %
PA:3=0.47 %
PA:4=0.64 %
PA:5=0.81 %
PA:6=0.99 %
PA:7=1.16 %
PA:8=1.33 % (d)
PA:9=1.50 %
Ion
SMOKE (ION)
(See notes
*
and
†
)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 % (d)
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 % (d)
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6=1.25 % (d)
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
FlashScan View
®
Laser
(See Note
‡
)
AL:1=0.02 %
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 % (d)
AL:7=1.00 %
AL:8=1.50 %
AL:9=2.00 %
AL:1=0.02 %
AL:2=0.03 %
AL:3=0.05 %
AL:4=0.10 %
AL:5=0.20 %
AL:6=0.50 % (d)
AL:7=1.00 %
AL:8=1.50 %
**
AL:9=2.00 %
PA:1=Auto
PA:2=0.02 %
PA:3=0.05 %
PA:4=0.10 %
PA:5=0.20 %
PA:6=0.50 % (d)
PA:7=0.70 %
PA:8=1.00 %
PA:9=1.50 %
Acclimate Plus™
(See Note
††
)
AL:1=0.50 %
AL:2=1.00 %
AL:3=1.00 to 2.00 %
AL:4=2.00 %
AL:5=2.00 to 3.00 % (d)
AL:6=3.00 %
AL:7=3.00 to 4.00 %
AL:8=4.00 %
AL:9=thermal 135
o
F
Alarm (CLIP)
AL:1=1.00 %
AL:2=1.00 %
AL:3=1.00 to
2.00 %
AL:4=2.00 %
AL:5=2.00 to
4.00 % (d)
AL:6=2.00 to
4.00 %
AL:7=2.00 to
4.00 %
AL:8=4.00 %
AL:9=4.00 %
PA:1=0.50 %
PA:2=1.00 %
PA:3=1.00 %
PA:4=1.00 to 2.00 %
PA:5=1.00 to 2.00 % (d)
PA:6=2.00 %
PA:7=2.00 %
PA:8=2.00 to 3.00 %
PA:9=2.00 to 3.00 %
Beam Detector
(See Note
‡‡
)
AL:1=25 %
AL:2=30 %
AL:3=40 %
AL:4=50 %
AL:5=30 - 50 %
AL:6=40 - 50 %
AL:1=25 %
AL:2=30 %
AL:3=40 %
AL:4=50 %
AL:5=30 - 50 %
AL:6=40 - 50 %
N/A
