Honeywell Notifier NFS2-640/E User Manual

114 NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14
Type Codes Type Codes for Input Devices
F.4.3 Type Codes for Monitor Modules
A list of monitor module Type Codes, which you can use to change the function of a monitor
module point.
1
CLIP Mode only
2
Requires approval of AHJ.
3
Not suitable for Canadian applications.
4
LED representation of a CO alarm may be performed using an ACS annunciator.
5
Photo element can be programmed as latching or tracking for all Photo/Co devices programmed as this type ID via VeriFire Tools.
Table F.1 Intelligent Detector Type Codes (3 of 3)
Table F.2 Type Codes for Monitor Modules (1 of 2)
Type Code
Point Characteristics
Device Function
Point
Type
Latching
(Y/N)
Point Function
MONITOR fire alarm Y Lights fire alarm LED and activates CBE Alarm-monitoring device
PULL STATION fire alarm Y Lights fire alarm LED and activates CBE Manual fire-alarm-activating device, such as a pull
station
RF MON MODUL fire alarm Y Lights fire alarm LED and activates CBE Wireless alarm-monitoring device
RF PULL STA fire alarm Y Lights fire alarm LED and activates CBE Wireless manual fire-alarm-activating device, such as a
pull station
SMOKE CONVEN fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
SMOKE DETECT fire alarm Y Lights fire alarm LED and activates CBE Indicates activation of a conventional smoke detector
attached to an FZM-1
WATERFLOW fire alarm Y Lights fire alarm LED and activates CBE Monitor for waterflow alarm switch
WATERFLOW S supervisory Y Lights supervisory LED and activates CBE Indicates supervisory condition for activated waterflow
switch
ACCESS MONTR non-alarm N Activates CBE Used for monitoring building access
AREA MONITOR security Y Lights security LED and activates CBE Monitors building access
AUDIO SYSTEM trouble N Lights trouble LED Used for monitoring audio equipment
EQUIP MONITR security N Activates CBE Used for recording access to monitored equipment
RF SUPERVSRY supervisory N Lights Supervisory LED Monitors a radio frequency device
SECURITY security Y Lights security LED Indicates activation of security alarm
LATCH SUPERV supervisory Y Lights supervisory LED Indicates latching supervisory condition
TRACK SUPERV supervisory N Lights supervisory LED Monitors for waterflow tamper switches for alarm points
SYS MONITOR security Y Lights security LED and activates CBE Monitors equipment security
TAMPER supervisory Y Lights supervisory LED, activates CBE Indicates activation of tamper switch
ACK SWITCH non-alarm N Performs Acknowledge function, no CBE Silences panel sounder, gives an Acknowledge
message on the panel LCD
ALLCALL PAGE non-alarm N Activates all speaker circuits, no CBE Performs AMG-1 All-call
DRILL SWITCH non-alarm N Performs Drill function Activates silenceable outputs
EVACUATE SWITCH non-alarm N Performs Drill function Activates all silenceable outputs
FIRE CONTROL non-alarm N Activates CBE Used for non-fire activation of outputs
NON FIRE non-alarm N Activates CBE Used for building energy management
PAS INHIBIT non-alarm N Inhibits Positive Alarm Sequence Inhibits Positive Alarm Sequence
POWER MONITR trouble N Indicates trouble Monitors auxiliary power supplies
RESET SWITCH non-alarm N Performs Reset function Resets control panel
SIL SWITCH non alarm N Performs Signal Silence function Turns off all activated silenceable outputs
TELE PAGE non-alarm N Performs function of Page Button on FFT-7 Allows remote paging to a fire area
DISABLE MON disable N When a point with this type code activates,
it will create a disable on the panel for that
point. No CBE generated.
Module can not be disabled via ACS, Alter Status, or
over the network.
TROUBLE MON trouble N Indicates Trouble Monitors trouble inputs
ABORT SWITCH non alarm N Indicates Active at the panel Aborts activation of a releasing zone
MAN RELEASE fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module programmed to
releasing zone to perform a releasing function
MANREL DELAY fire alarm Y Lights Fire Alarm LED and activates CBE Indicates activation of a monitor module programmed
for a release output
SECOND SHOT fire alarm Y Indicates Active at the panel and activates
CBE
Provides second activation of releasing zone after soak
timer has expired.
Blank fire alarm Y Lights fire alarm LED and activates CBE Monitors for a device with no description
HEAT DETECT fire alarm Y Lights fire alarm LED and activates CBE Monitors for conventional heat detector
