NFS2-640/E Programming Manual — P/N 52742:L2 7/17/14 113

Type Codes for Input Devices Type Codes

SUP.L(DUCTP)

supervisory Y lights supervisory LED Photoelectric smoke detector used as a duct detector

to report supervisory condition rather than alarm.

Latching.

SUP.T(PHOTO)

2,3

supervisory N lights supervisory LED Photoelectric smoke detector used to report

supervisory condition rather than alarm. Tracking.

SUP.L(PHOTO)

supervisory Y lights supervisory LED Photoelectric smoke detector used to report

supervisory condition rather than alarm. Latching.

RF_PHOTO

fire alarm Y lights fire alarm LED and activates CBE Wireless Photoelectric smoke detector

SMOKE(HARSH)

fire alarm Y lights fire alarm LED and activates CBE HARSH smoke detector

PHOTO/CO

fire alarm Y lights fire alarm LED for photo and heat,

no LED will light for a CO alarm,

photo and heat will activate CBE, CO

alarm activates special function zone FC

and sixth CBE zone only (sixth CBE zone

programmable via VeriFire Tools)

Photoelectric, Carbon Monoxide, and Heat detector

PHOTO/CO (P

SUP)

2,4,5

fire alarm/

supervisory

Y lights fire alarm LED for heat, no LED will

light for a CO alarm, supervisory LED will

light for photo alarm,

heat and photo will activate CBE, CO

alarm activates special function zone FC

and sixth CBE zone only (sixth CBE zone

programmable via VeriFire Tools)

Photoelectric, Carbon Monoxide, and Heat detector

PHOTO/CO (C SUP)

fire alarm/

supervisory

Y lights fire alarm LED for heat and photo

alarms, will light supervisory LED for CO

alarm, photo and heat alarms will activate

CBE, CO alarm will activate sixth CBE

zone only (sixth CBE zone programmable

via VeriFire Tools)

Photoelectric, Carbon Monoxide, and Heat detector

SMOKE(BEAM)

fire alarm Y lights fire alarm LED and activates CBE Beam smoke detector

SMOKE(LASER)

fire alarm Y lights fire alarm LED and activates CBE Laser smoke detector

SUP.L(LASER)

supervisory Y lights supervisory LED Laser smoke detector used to report supervisory

condition rather than alarm. Latching.

SUP.T(LASER)

2,3

supervisory N lights supervisory LED Laser smoke detector used to report supervisory

condition rather than alarm. Tracking.

SMOKE(DUCTL)

fire alarm Y lights fire alarm LED and activates CBE Duct Laser smoke detector

SUP T(DUCTL)

supervisory N lights supervisory LED Laser smoke detector used as a duct detector to

report supervisory condition rather than alarm.

Tracking.

SUP L(DUCTL)

supervisory Y lights supervisory LED Laser smoke detector used as a duct detector to

report supervisory condition rather than alarm.

Latching.

AIR REF

fire alarm Y lights fire alarm LED and activates CBE Assign to one or more FSL-751 detectors used to

monitor the quality of air entering the protected area.

The air quality measurement allows the VIEW

system to compensate for vehicle fumes, fog, or other

particles brought into the protected area through the

ventilation system. Poor air quality will lower the

sensitivity of all FSL-751 detectors on the SLC. The

detector sensitivity, however, remains within approved

limits (always less than 1% obscuration per foot).

NOTE: A reference detector still functions as a smoke detector, but you should set the detector sensitivity level to the least sensitive level—AL:9 and

PA:9 Change Alarm and Pre-Alarm sensitivity. Refer to “Detector Sensitivity Settings” on page 101 for a complete list of detector sensitivity settings.

HEAT

fire alarm Y lights fire alarm LED and activates CBE 190

F intelligent thermal sensor

HEAT+

fire alarm Y lights fire alarm LED and activates CBE 190

F intelligent thermal sensor with low temperature

warning.

HEAT(FIXED)

fire alarm Y lights fire alarm LED and activates CBE 135

F intelligent thermal sensor

HEAT (ROR)

fire alarm Y lights fire alarm LED and activates CBE 15
