Adding a thermostat to the BACnet network
The following procedure explains adding the TC300 thermostat to a Bacnet net-
work using the Niagara 4 workbench.
1. In the Niagara 4 workbench, create a new Station.
2. To configure the BACnet device, click Station > Config > Drivers >
BacnetNetwork > Local Device in the Nav view.
The property sheet of the local BACnet device appears in the right view.
Fig 6. Local Device Property Sheet
3. On the property sheet, change the Object Id to any other number instead of -1
and click Save.
4. In the Nav view seen on the left, click BACnet Comm > Network > MstpPort >
Link.
The property sheet of the MSTP port page appears.
