Honeywell TC300

32 Terminal input
Terminal input
Terminal output and network output
Table 5 Terminal input
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
phy_ChangeOverSwitch Binary Input 1 0 Close=0,
Open=1
Changeover switch
status
phy_DatSensor Analog
Input
1 -40 to 200 °F Discharge air sensor
output value
phy_DrainpanSensor Binary Input 2 0 Off=0,
On=1
Drain pan sensor status
phy_OccupancySensor Binary Input 3 0 Standby=0
Unoccupied=1
Occupancy sensor status
phy_ProofOfAirFlowSensor Binary Input 4 0 Off=0
On=1
Proof of air flow sensor
status
phy_PipeSensor Analog
Input
2 -40 to 260 °F Pipe sensor output value
phy_SpaceTempSensor Analog
Input
3 -40 to 150 °F Space temperature
sensor output value
Table 6 Terminal output and network output
Name
BACnet
Object
Type
BACnet
Object
Instance
Range Description
no_SixWay_Valve_Cooling Analog
Output
2001 0 to 100% Six-way valve cooling control output
no_SixWay_Valve_Heating Analog
Output
2002 0 to 100% Six-way valve Heating control output
no_Modulating_Cool Analog
Output
2003 0 to 100% Modulating cool control output
no_Modulating_Heat Analog
Output
2004 0 to 100% Modulating heat control output
no_VariableFan Analog
Output
2005 0 to 100% Variable Fan control output
no_Auxiliary_Heat Binary
Output
2001 Off=0,On=1 Auxiliary heat control output
no_ChangeOverValve Binary
Output
2002 Off=0,On=1 Changeover valve control output
no_Cooling_Valve(On/Off) Binary
Output
2004 Off=0,On=1 Cooling on/off valve output status
no_Heating_Valve(On/Off) Binary
Output
2005 Off=0,On=1 Heating on/off valve output status
