64 Discharge air control
Discharge air control
Sylk calibration offsets
Table 29 Discharge air control
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_FanCoilSupTempHtgSp Analog
Value
1723 85 °F 75 to 180 °F Discharge air control
maximum heating setpoint.
Cfg_FanCoilSupTempClgSp Analog
Value
1724 55 °F 40 to 80 °F Discharge air control
minimum cooling setpoint.
Cfg_FanCoilDATSpEnSwitch Binary
Value
454 0 Off=0,
On=1
Discharge air control enable
flag
Cfg_FanCoilDATHeatOffset Analog
Value
2009
0
Δ°F 0 to 90 Δ°F
Discharge air control heating
initial offset
Cfg_FanCoilDATCoolOffset Analog
Value
2010
0
Δ°F 0 to 40 Δ°F
Discharge air control cooling
initial offset
Cfg_DaT_Ctrl_Cool_Tr Analog
Value
2011
6
Δ°F 0 to 30 Δ°F
Discharge air control cooling
throttling range
Cfg_DaT_Ctrl_Cool_It Analog
Value
2012 300
seconds
0 to 5000
seconds
Discharge air control cooling
integral time
Cfg_DaT_Ctrl_Heat_Tr Analog
Value
2014
6
Δ°F 0 to 30 Δ°F
Discharge air control heating
throttling range
Cfg_DaT_Ctrl_Heat_It Analog
Value
2015 300
seconds
0 to 5000
seconds
Discharge air control heating
integral time
Table 30 Sylk calibration offsets
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_LocalSensCalOffset
_Temp
Analog
Value
23 0 °F -10 to 10 °F Local onboard temperature
sensor calibration offset
Cfg_LocalSensCalOffset
_Hum
Analog
Value
103 0%RH -10 to 10%RH Local onboard humidity
sensor calibration offset
Cfg_SylkCalOffset_Sylk
Bus2Temp
Analog
Value
24 0 °F -10 to 10 °F TR40_2/ TR-21
temperature calibration
offset
Cfg_SylkCalOffset_Sylk
Bus2RH
Analog
Value
25 0%RH -10 to 10%RH TR40_2 humidity calibration
offset
Cfg_SylkCalOffset_Sylk
Bus2CO2
Analog
Value
100 0 °F -100 to 100 ppm TR40_2 CO2 calibration
offset
Cfg_SylkCalOffset_Sylk
Bus3Temp
Analog
Value
26 0 °F -10 to 10 °F TR40_3 temperature
calibration offset
Cfg_SylkCalOffset_Sylk
Bus4Temp
Analog
Value
27 0 °F -10 to 10 °F TR40_4 temperature
calibration offset
