Honeywell TC300

IO configuration 33
IO configuration
no_Cooling_Floating_Open Binary
Output
2006 Off=0,On=1 Cooling floating valve open control
output
no_Cooling_Floating_Close Binary
Output
2007 Off=0,On=1 Cooling floating valve close control
output
no_Heating_Floating_Open Binary
Output
2008 Off=0,On=1 Heating floating valve open control
output
no_Heating_Floating_Close Binary
Output
2009 Off=0,On=1 Heating floating valve close control
output
no_High_Single_Speed_Fan Binary
Output
2010 Off=0,On=1 High speed fan on/off status
no_Low_Speed_Fan Binary
Output
2011 Off=0,On=1 Low speed fan on/off status
no_Medium_Speed_Fan Binary
Output
2012 Off=0,On=1 Medium speed fan on/off status
no_Modulating_Cooling_stage_1 Binary
Output
2014 Off=0,On=1 Modulating cool stage1 on/off status
no_Modulating_Heating_stage_1 Binary
Output
2015 Off=0,On=1 Modulating heat stage1 on/off status
Table 7 IO configuration
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_OccSensChar Binary
Value
31 0 NormallyOpen=0,
NormallyClosed=1
Occupancy sensor
input characteristics
selection
Cfg_AirFlwStsChar Binary
Value
33 0 NormallyOpen=0,
NormallyClosed=1
Airflow status input
characteristics
selection
Cfg_UISensCalOffset_DATemp Analog
Value
185 0 °F -10 to 10 °F Universal input
discharge air
temperature
calibration offset
Cfg_SpcSensChar Multistate
Value
372 3 enum{
NTC10KTypeII=1,
NTC10KTypeIII=2,
NTC20K=3}
Space temperature
Sensor characteristic
selection
Cfg_UISensCalOffset_SpcTem
p
Analog
Value
1464 0 °F -10 to 10 °F Space temperature
calibration offset
Table 6 Terminal output and network output (Continued)
Name
BACnet
Object
Type
BACnet
Object
Instance
Range Description
