Honeywell TC300

34 IO configuration
Cfg_ModHeatMin_Output Analog
Value
1475 2 V 0 to 9 V Minimum output
voltage when
modulating heating
is enabled
Cfg_ModHeatAction Binary
Value
380 0 Direct=0,
Reverse=1
Modulating heat
polarity selection
Cfg_ModCoolMin_Output Analog
Value
1476 2 V 0 to 9 V Minimum output
voltage when
modulating cooling
is enabled
Cfg_ModCoolAction Binary
Value
381 0 Direct=0,
Reverse=1
Modulating cool
polarity selection
Cfg_VarSpeedFanType Multistate
Value
373 2 enum{0-10V=1,
2-10V=2}
Variable fan speed
type characteristic
selection
Cfg_ModHeatMax_Output Analog
Value
1477 10 V 1 to 10 V Maximum voltage on
heating output.
Cfg_ModCoolMax_Output Analog
Value
1478 10 V 1 to 10 V Maximum voltage on
cooling output.
Cfg_PipeSensChar Multistate
Value
2005 3 enum{
NTC10KTypeII=1,
NTC10KTypeIII=2,
NTC20K=3}
Pipe sensor type
Cfg_DASensChar1 Multistate
Value
503 3 enum{
NTC10KTypeII=1,
NTC10KTypeIII=2,
NTC20K=3}
Discharge air sensor
type
Cfg_LeakDetectorSensorChar Binary
Value
455 1 NormallyOpen=0,
NormallyClosed=1
Leak detector/Drain
pan sensor
characteristics
Table 7 IO configuration (Continued)
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
