Honeywell TC300

28 IO status
IO status
IO Assignment
Table 3 IO status
Name
BACnet
Object Type
BACnet
Object
Instance
Range Description
no_UIO3 Analog
Output
2006 -40 to 260 Universal Output shared to network.
no_UIO1 Analog
Output
64 -40 to 260 Universal Output shared to network.
no_UIO2 Analog
Output
63
-40 to 260 Universal Output shared to network.
no_DO1 Binary Output 74 Off=0,
On=1
Digital Output shared to network.
no_DO2 Binary Output 75 Off=0,
On=1
Digital Output shared to network.
no_DO3 Binary Output 76 Off=0,
On=1
Digital Output shared to network.
no_DIO1 Binary Output 77 Off=0,
On=1
Digital Output shared to network.
no_DIO2 Binary Output 78 Off=0,
On=1
Digital Output shared to network.
Table 4 IO assignment
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_UIO1 Multistate
Value
26 1 enum{None=1,
6-wayValve=2,
ModulatingCool=3,
ModulatingHeat=4,
ModulatingValve=5,
VariableSpeedFan=6,
DischargeAirSensor=7,
DrainPanSensor=8,
OccupancySensor=9,
ProofofAirflow=10,
PipeSensor=11,
SpaceTempSensor=12,
ChangeoverSwitch=13}
enum{None=1,
6-wayValve=2,
ModulatingCool=3,
ModulatingHeat=4,
ModulatingValve=5,
VariableSpeedFan=6,
DischargeAirSensor=7,
DrainPanSensor=8,
OccupancySensor=9,
ProofofAirflow=10,
PipeSensor=11,
SpaceTempSensor=12,
ChangeoverSwitch=13}
