Honeywell TC300

Fan speed 51
Fan speed
Heating configuration
Table 18 Fan speed
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_FanCoilTwoSpeedVentMo
de
Multistate
Value
585 1 enum{Low=1,
High=2}
Fan speed for
ventilation
mode
Cfg_FanCoilThreeSpeedVentM
ode
Multistate
Value
586 1 enum{Low=1,
Medium=2,
High=3}
Fan speed for
ventilation
mode
Cfg_FanCoilTwoSpeedType Multistate
Value
581 2 enum{
MultipleOutputsAtATime=1
OneOutputAtATime=2}
Two speed fan
output type
Cfg_FanCoilThreeSpeedType Multistate
Value
582 2 enum{
MultipleOutputsAtATime=1
OneOutputAtATime=2}
Three speed
fan output
type
Cfg_VarSpeedFan_VentSpeed Analog
Value
1470 20% 0 to 100% Variable speed
fan speed for
ventilation
mode
Cfg_VarSpeedFan_CoolMinSpe
ed
Analog
Value
1468 20% 0 to 100% Variable speed
fan min speed
for cool
Cfg_VarSpeedFan_CoolMaxSp
eed
Analog
Value
1469 100% 0 to 100% Variable speed
fan max speed
for cool
Cfg_VarSpeedFan_HeatMinSp
eed
Analog
Value
1473 10% 0 to 100% Variable speed
fan min speed
for heat
Cfg_VarSpeedFan_HeatMaxSp
eed
Analog
Value
1474 50% 0 to 100% Variable speed
fan max speed
for heat
Table 19 Heating configuration
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
Cfg_Heat_Tr Analog
Value
54
4
Δ°F 0 to 30 Δ°F
Heating throttling range.
Cfg_Heat_It Analog
Value
55 2500
seconds
0 to 5000
seconds
Heating integral time
0 = disable (i.e., proportional
only)
Cfg_Heat_DischHiLimSp Analog
Value
61 150 °F 60 to 200 °F Discharge air temperature
high limit setpoint
