Honeywell TC300

30 IO Assignment
Cfg_DO2 Multistate
Value
29 9 enum{None=1,
HeatingFloatingClose=7,
CoolingFloatingClose=8,
CoolingOn/Off=9,
ValveFloatingClose=10,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
CoolStage1=31}
enum{None=1,
HeatingFloatingClose=7,
CoolingFloatingClose=8,
CoolingOn/Off=9,
ValveFloatingClose=10,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
CoolStage1=31}
Cfg_DO3 Multistate
Value
30 1 enum{None=1,
CoolingFloatingOpen=4,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
HeatStage1=30,
CoolStage1=31}
enum{None=1,
CoolingFloatingOpen=4,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
HeatStage1=30,
CoolStage1=31}
Cfg_DIO1 Multistate
Value
31 1 enum{None=1,
CoolingFloatingClose=8,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
DischargeAirSensor=18,
DrainPanSensor=19,
OccupancySensor=20,
ProofOfAirflow=21,
PipeSensor=22,
SpaceTempSensor=23,
ChangeoverSwitch=24}
enum{None=1,
CoolingFloatingClose=8,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
DischargeAirSensor=18,
DrainPanSensor=19,
OccupancySensor=20,
ProofOfAirflow=21,
PipeSensor=22,
SpaceTempSensor=23,
ChangeoverSwitch=24}
Cfg_DIO2 Multistate
Value
32 12 enum{None=1,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
DischargeAirSensor=18,
DrainPanSensor=19,
OccupancySensor=20,
ProofOfAirflow=21,
PipeSensor=22,
SpaceTempSensor=23,
ChangeoverSwitch=24}
enum{None=1,
ChangeoverValve=11,
FanCommand=12,
HighSpeedFan=13,
MediumSpeedFan=14,
LowSpeedFan=15,
AuxiliaryHeat=16,
DischargeAirSensor=18,
DrainPanSensor=19,
OccupancySensor=20,
ProofOfAirflow=21,
PipeSensor=22,
SpaceTempSensor=23,
ChangeoverSwitch=24}
Table 4 IO assignment (Continued)
Name
BACnet
Object
Type
BACnet
Object
Instance
Default
Value
Range Description
