Honeywell Thor VM3 Manual

5 - 26
UPS
When the Thor VM3 is operating on the UPS the timeouts from the battery section for the selected power scheme/
plan are used. By default, the timeouts for UPS are the same for each power scheme/plan.
UPS Behavior
The Thor VM3 behavior when operating from UPS power is described below.
Thor VM3 is Off
Conditions
The Thor VM3 is Off and the power button is pressed the Thor VM3 and the following condition is met:
• UPS power is over 35% capacity
Result
The Thor VM3 boots and follows the selected power scheme's Running on Batteries (or power plan’s On
battery) timeouts with power management timers reset at boot up.
Conditions
The Thor VM3 is Off and the power button is pressed the Thor VM3 and the following condition is met:
• UPS power is under 35% capacity
Results
The Thor VM3 remains Off.
Thor VM3 is On
Conditions
The Thor VM3 is On and external power is removed, such as:
• Thor VM3 is removed from a powered dock (Dock power switch On)
• Thor VM3 is mounted to a dock and truck power is removed from the dock
• Thor VM3 is mounted to a dock and the dock power switch is turned Off
Result
The Thor VM3 boots and follows the selected power scheme's Running on Batteries (or power plan’s On
battery) timeouts with power management timers reset at the time of power removal. UPS charging is
disabled.
Power Notification Icon
The Power icon in the notification area provides an indication of the level of UPS battery charge. The icon also
indicates if external power is connected. Some samples are shown below
External power is connected and the UPS battery is approximately 50% charged.
External power not connected and the UPS battery is approximately 100% charged.

Honeywell Thor VM3 Specifications

General

Stepping	D0
Tjunction	-40 °C
FSB Parity	No
Processor code	SR1X8
Processor cache	1 MB
Processor cores	2
Processor model	E3826
System bus rate	- GT/s
Processor family	Intel Atom®
Processor codename	Bay Trail
Processor frequency	1.46 GHz
Processor cache type	L2
Processor manufacturer	Intel
Processor package size	25 x 27 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	22 nm
PCI Express configurations	1x1, 1x4, 2x1
Thermal Design Power (TDP)	7 W
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Storage media	Flash
Compatible memory cards	-
Internal storage capacity	64 GB
Display diagonal	12.1 \
Display brightness	900 cd/m²
Display resolution	1024 x 768 pixels
Graphics card	HD Graphics
Rear camera resolution (numeric)	- MP
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	1
I/O ports	1x CAN-bus, RF
Processor ARK ID	78477
Processor socket	BGA 1170
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Platform	Windows
Bundled software	Data Collection Engine, Microsoft Internet Explorer, Microsoft on-screen keyboard, Configuration Cloning Utility, Screen Blanking, Zoom Zone, Launcher
Operating system installed	Windows 7
AC adapter input voltage	90 - 240 V
Battery capacity	- mAh
Battery life (max)	0.5 h
Certification	EN 55024:2010, MIL-STD-810F, SAE-J1455, CCX
Device type	Tablet PC
Form factor	Slate
Product color	Grey, Silver
Protection features	Shock resistant, Vibration proof, Water resistant
International Protection (IP) code	IP66
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	62 mm
Width	318 mm
Height	260 mm
Weight	3000 g
