Talkman Device Charger and Battery Charger Wall
Mount
The A700 device charger and the A700 battery charger are ready for mounting
on a standard DIN rail without any customer modifications. A DIN rail must be
installed on a wall in a suitable location. Honeywell offers a DIN rail suitable for
mounting a single charger, but customers may choose to purchase rails from
other suppliers as long as the rails meet Honeywell specifications. Consider the
following before wall mounting your charger.
l Customer assembly required for the rail wall mount.
l Customer assumes all responsibility for the installation of charger units.
l Installer must verify that the installation meets all local building codes.
l Avoid potential hazards (electrical wires, waterlines, and similar building
components) when drilling into the wall.
l Avoid blocking power outlets and other wall receptacles when installing the
rail and charger.
l Anchoring a wall mount rail to a wall stud generally results in a more stable
installation. If you drill into a wall stud, do not use a screw anchor in that
hole.
l If you are mounting two chargers side by side, you must leave at least 1 in.
(2.54 cm.) of space between the two units to allow clearance for the locking
arms.
l Rails must be anchored to the wall at least 12 in. (30.5 cm.) from the floor to
allow for proper attachment, seating, and removal of the charger unit.
l If you are mounting a charger directly above another charger, Honeywell
recommends clearance of at least 10 in. (25.4 cm.) between DIN rails.
The following image shows the back of the charger and points of interest for
mounting the charger to the wall.
35 A700x Product Guide
