IMPORTANT
The power supply for the charger should already be zip-tied in the back
of the charger chassis. If it is not, plug the power supply into the
charger and secure it. Do not plug it into a power source until after
mounting is complete.
2. Before attaching the charger to the rail, open the locking arms on the back
of the unit by rotating the two levers out on each side of the charger. The
arms are parallel to the floor in the unlocked position.
3. Attach the charger to the DIN rail by hanging the two hooks on the back of
the unit on the top lip of the rail.
4. Slide the charger horizontally to the desired position on the rail, and rotate
the locking arms into the locked position - flush with both sides of the unit.
5. If the charger does not feel secure on the rail, adjust the rubber stops on the
back of the unit by screwing them out toward the wall.
6. Plug the power supply into a power source and check the LED indicator at
the bottom right of the charger face. If the indicator light is a solid green,
the charger is powered on.
SRX2 and A700 Battery Charger LED Indicators
The A700 battery charger charges standard or high capacity batteries for the
A700 and the A700x. Although the batteries may differ in color, the A700 and
A700x batteries are interchangeable.
The SRX2 battery charger and the A700 battery charger have an LED indicator
light, located at the bottom right of the charger face, that signals the status of
the charger.
l Solid green LED: Charger power is on
l No light: Charger power is off
l Solid red LED: Charger is experiencing a power fault (SRX2 only)
NOTE
If the charger LED indicator is red, unplug the charger power supply
from the power source, and remove all batteries. Plug the power supply
into the power source again. If the LED remains red, the charger may
require repair or replacement.
Charger Port Indicators
Additionally, each battery port has two LED indicator lights that apply to the
status of the resident battery.
l The ring LED is a circular light that indicates the battery's charge status.
l The alert LED, in the shape of an exclamation point (!), indicates that there is
a battery condition requiring attention. When this indicator is on, the battery
on that charger port may not last a full shift. Check VoiceConsole for a
specific alert message.
37 A700x Product Guide
