Quantity Description
1 Vehicle Mount, Clamp
1 Vehicle Mount, Arm
1 Vehicle Mount, Holder
1 Vehicle Mount, Holder/Base Screw On Attachment
The following parts are supplied by Honeywell for attaching the claw mount:
Quantity Description
1 Vehicle Mount, Claw
1 Vehicle Mount, Arm
1 Vehicle Mount, Holder
1 Vehicle Mount, Holder/Base Screw On Attachment
1. Drill the holes required to secure the base to the vehicle. If using the clamp
or claw mount, skip this step.
Apply some lubricant (for example, light oil or anti-seize) to the threads of
the clamp mount screws.
2. Screw or clamp a base to the location.
3. Attach the other base to the other end of the arm and tighten once in the
desired location by turning the locking lever clockwise.
4. Screw the device holder to the base.
5. Insert a device into the holder.
To prevent vibration, the arm of the mounting bracket should not touch the
stem of the ball of the base. In other words, the arm should not be tilted so
far as to have these pieces touching.
43 A700x Product Guide
