Honeywell XENON 1900 User Manual

Xenon/Granit User Guide 105
Delete Last Code
If you want to delete the last bar code scanned when in Batch Mode, scan Delete
Last Code.
Clear All Codes
If you want to clear the scanner’s buffer of all data accumulated in Batch Mode,
scan Clear All Codes.
Transmit Records to Host
If you are operating in Inventory Batch Mode (see Inventory Batch Mode on page
101), you must scan the following bar code to transmit all the stored data to the
host system.
Batch Mode Transmit Delay
Sometimes when accumulated scans are sent to the host system, the transmission
of those scans is too fast for the application to process. To program a transmit
delay between accumulated scans, scan one of the following delays. Default = Off.
Note: In most cases, a short (250 ms (milliseconds)) delay is ideal, however, longer delays
may be programmed. Contact Technical Support (page xvii) for additional
information.
Delete Last Code
Clear All Codes
Transmit Inventory Records
* Batch Mode Transmit Delay Off
(No Delay)

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
