Honeywell XENON 1900 User Manual

188 Xenon/Granit User Guide
All Symbologies
For best scanner performance, we recommend you only enable the symbologies
that you need. Scan All Symbologies Off to disable all symbologies, then enable
the symbologies you need by scanning the On bar code for each symbology.
Message Length Description
You are able to set the valid reading length of some of the bar code symbologies.
You may wish to set the same value for minimum and maximum length to force the
scanner to read fixed length bar code data. This helps reduce the chances of a mis-
read.
Example: Decode only those bar codes with a count of 9-20 characters.
Min. length = 09
Max. length = 20
Example: Decode only those bar codes with a count of 15 characters.
Min. length = 15
Max. length = 15
For a value other than the minimum and maximum message length defaults, scan
the bar codes included in the explanation of the symbology, then scan the digit
value of the message length and Save bar codes from the Programming Chart,
beginning on page 353. The minimum and maximum lengths and the defaults are
included with the respective symbologies.
Codabar
<Default All Codabar Settings>
Codabar On/Off
All Symbologies Off
* On

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
