Honeywell XENON 1900 User Manual

308 Xenon/Granit User Guide
Xenon 1902g-BF Scanner Product Specifications
Parameter Specification
Mechanical
Height 6.3 inches (160mm)
Length 4.1 inches (104.1mm)
Width 2.8 inches (71.1mm)
Weight 6.9 ounces (195g)
Electrical
Illumination LED:
Peak Wavelength 624nm + 18nm (red LED)
IEC 62471: “Exempt Risk Group”
442nm, 552nm (white LED)
IEC 62471: “Exempt Risk Group”
Aiming:
Peak Wavelength Laser 650nm
IEC 60825-1: “Class 2”
Peak Wavelength LED 624nm + 18nm (red LED)
520nm + 18nm (green LED)
IEC 62471: “Exempt Risk Group”
Optical Power Laser <1mW
Radio
Frequency 2.4 to 2.5 GHz (ISM Band) Frequency Hopping
Bluetooth v.2.1
Range 33 ft. (10 m) typical
Data Rate Up to 1 MBps
Environmental
Temperature Ranges:
Operating 32 F to +122 F (0 C to 50 C)
Storage -40F to +158F (-40C to 70C)
Humidity Up to 95% non-condensing
Mechanical Drop Operational after 50 drops from 3.3 feet
(1 m) to concrete
Vibration Withstands 5G peak from 22 to 300 Hz
ESD Sensitivity Up to 15kV direct air
Up to 8 kV indirect coupling plane
Sealant Rating IP41
Image Size 838 x 640 pixels
Scan Performance
Skew Angle +65°
Pitch Angle +
45°

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
