Honeywell XENON 1900 User Manual

158 Xenon/Granit User Guide
Direct Illumination - Top and Bottom
This setting enables both top and bottom illumination. It is recommend when read-
ing printed label bar codes and DPMs on highly reflective surfaces.
Direct Illumination - Bottom
This setting enables just the bottom illumination. It is recommend when primarily
reading dot peen bar codes. You may need to tilt the scanner at an angle to read
from reflective surfaces.
Indirect Illumination
This setting is recommend when reading bar codes on curved or rough surfaces.
Low Contrast Data Matrix Enhancements
The Granit 1920i scanner reads low contrast Data Matrix codes by default. How-
ever, if you are having trouble reading non-dot peen Data Matrix bar codes, it may
be helpful to scan Low Contrast Data Matrix Enhancements Off
. Default = Low
Contrast Data Matrix Enhancements On.
Direct Illumination -
Top and Bottom
Direct Illumination -
Bottom
Indirect Illumination
* Low Contrast Data Matrix
Enhancements On

Honeywell XENON 1900 Specifications

General

Type	Handheld bar code reader
Sensor type	Laser
Scanner type	1D/2D
Pitch reading angle	-45 - 45 °
Linear (1D) barcodes supported	-
Standard interfaces	USB, Keyboard wedge, RS-232, RS-485
Connectivity technology	Wired
Input voltage	4 - 5.5 V
Power consumption	450 mA
Power source type	DC
Power consumption (standby)	0.45 W
Power consumption (typical)	2.3 W
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Sustainability certificates	RoHS

Weight and Dimensions

Depth	104 mm
Width	71 mm
Height	160 mm
Weight	147 g
