UV-Scan
14 #03592DE-EN c
5. Use of teas
®
UV Strips
Tesa UV Strips are suitable for the precise, rapid measurement of UV
doses. The strips measure the density of energy affecting their surface in
mJ/cm2. UV radiation causes the strip material to turn red, which can be
evaluated and displayed using the UV-Scan measuring device.
5.1. Technical data of tesa UV strips
Tesa UV-Strip
Spectral sensitivity
see diagram
Maximum sensitivity
256 nm
Maximum irradiation dose
200 mJ/cm2
Minimum speeds:
one lamp with 120 W/cm
three lamps with 120 W/cm
30 m/min
40 m/min
Precision
+/- 15%
min. +/- 5
mJ/cm2
Temperature range on measurement
15 – 40 °C
Storage temperature
0 – 25 °C
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
1
200 250 300 350 400
Sensitivity
Wavelength
Spectral sensitivity of UV-Strip measuring strips
