honle UV-Scan - 17 Technical Data; Uv-Scan; Power-Supply Unit; Ambient Conditions

#03592DE-EN c 33
17. Technical data
17.1. UV-SCAN
Dimension in mm
177 mm x 124 mm
17.2. Power-supply unit
Input votage range
100 – 240 V
Frequenzy
50 – 60 Hz
Output voltage
9 V
Output current
1,1 A
17.3. Ambient conditions
Installation location
Only in closed rooms
Atmosphere
Without conductive dusts and no corrosive at-
mospheres; in particular, the atmosphere must
not contain chlorine, sulphur, acid or salt
Temperature range
UV-SCAN
+5 °C to +35 °C
Temperature range*
tesa
®
UV Strip
on measurement
on storage
15 – 40 °C
0 – 25 °C
Luftfeuchtigkeit
Maximum relative humidity 70 %
(non-condensing)
