Horton 4100-PLUS - Page 24

Installation
Articulated Push Arm (PF18.06 Standard) Minimum Reveal
220 100
683
25
"A"
Dimension "A" [mm]
10
30 50 70
30
PF18.07
50
PF18.08
70
PF18.09
90
PF18.10
Shaft Dimension [mm]
