Horton 4100-PLUS - Page 25

Installation
Extended Articulated Push Arm (PF18.13) Maximum Reveal
220 100
300 max
300 max
25
"A"
683
Dimension "A" [mm]
10
30 50 70
30
PF18.07
50
PF18.08
70
PF18.09
90
PF18.10
Shaft Dimension [mm]
