Horton 4100-PLUS - Page 26

Installation
Extended Articulated Push Arm (PF18.13) Minimum Reveal
220 100
150 min
683
150 min
25
"A"
Dimension "A" [mm]
10
30 50 70
30
PF18.07
50
PF18.08
70
PF18.09
90
PF18.10
Shaft Dimension [mm]
