Horton 4100-PLUS - Page 37

86
5
55
(spindle + 5)
45 5
150 max
DETAIL D
PF18.08 50mm Spindle
PF18.05 Slide Arm
Pull Mounting Angle, KAS312 - 38x38x3
Rail Packer
1
CW Mount Pull Sht.2
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
03/11/2016
SHEET 2 OF 3
SCALE:1:2
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
0104.4100-Plus S
Sht.2
DIMENSIONS IN MM
