Horton 4100-PLUS - Page 38

5
600
70
180
Pivot Pull Mounting Angle, KAS312 - 38x38x3
125 125 125 125
112 188 188 112 95
35
69.5
45
230
1
CW Mount Pull Sht.3
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
03/11/2016
SHEET 3 OF 3
SCALE:1:5
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
0104.4100-Plus S
Sht.3
DIMENSIONS IN MM
