Horton 4100-PLUS - Page 4

Pivot
55mm
Spindle + 5mm
25mm
292.5mm
0
Push Arm Elevation View
Horton Automatics Ltd
Unit A - Hortonwood 31
Telford, Shropshire TF1 7YZ
Adam Wiggans
07/11/2016
SHEET 2 OF 2
SCALE:1:5
DESCRIPTION:
REVISION
DO NOT SCALE DRAWING
DATE:
DRAWN
DWG NO:
4100 - Plus S
DIMENSIONS IN MM
