Horton 4100-PLUS - Page 40

Installation
Slide Pull Arm (PF18.05) Maximum Reveal (100mm)
100
100 max
220
180 600
"A"
Dimension "A" [mm] 35 55 75 95
30
PF18.07
50
PF18.08
70
PF18.09
90
PF18.10
Shaft Dimension [mm]
Pack to align
Slide rail with door frame
